CBA-III Circuit Breaker Analyzer
CBA-III takes SCM as core to sample, process and output, intelligent, multi-function, data accurate , strong anti-interference , simple operation, small size, light weight , beautiful appearance , etc.
Description
CBA-III takes SCM as core to sample, process and output, intelligent, multi-function, data accurate , strong anti-interference , simple operation, small size, light weight , beautiful appearance , etc. It applies to a variety of indoor, outdoor dynamic characteristics test for less oil, more oil switches, vacuum switches, and SF6 switches.
Product characteristics
1. Time: 12 contacts' fixed opening time and closing time, in-phase same time, out-phase same time.
2. Reclose: close-open, open-close, open-close-open for each breaker; process time: 1 opening time, 1 closing time, 2 closing time, metal short circuit time, no-current time.
3. Springing: closing springing time, springing numbers, springing waveform for each breaker; rebound magnitude for each breaker.
4. Speed: instant opening, closing speed, max speed, time-range characteristic curve.
5. Range: total range, open range, over-range, overriding range, rebound magnitude.
6. Current: opening/closing current of opening/closing coil, current waveform diagram.
7. Action voltage: DC30-250V/20A digital adjustable power circuit breaker, auto finish the breaker low voltage action test, measure the breaker action voltage.
|
Service condition input power |
220V±10% 50Hz±10% |
|
Atmospheric pressure |
86～106kpa ℃ |
|
Temperature |
－10～40℃ |
|
Humidity |
≦80% |
|
Rh-safety Performance-insulation resistance |
＞2MΩ |
|
Dielectric strength-power to chassis frequency voltage withstands |
1.5KV, 1 min, no flash over and arcing |
|
Basic parameters-time |
16000.0ms, resolution: 0.1m/s error: ①< 200ms, 0.1ms±1d ②>200ms, ±2％ ③synchronous, ±0.1ms |
|
Speed Range |
20.00m/s, resolution 0.01m/s error ①0～2m/s : ±0.1m/s±1d ②>2m/s, ±0.2m/s±1d |
|
Range Vacuum Circuit Breaker |
range- 50.0mm, resolution- 0.1mm error-±0.5mm SF6 |
|
Circuit Breaker |
range-300.0mm, resolution-0.1mm, error- ±2mm |
|
Oil-minimum breaker |
range-600.0mm, resolution-0.1mm, error- ±2mm |
|
Current Range |
20.00 A, resolution 0.01A Output power DC30～250V digitally adjustable /20A (Instantaneous work) |
|
Dimension & Weight Mainframe |
360mm×290mm×280mm, 6kg |
|
Accessories |
370mm×280mm×220mm, 9kg. |
|
No. |
Name |
QTY |
|
1 |
Host |
1 |
|
2 |
Speed signal transmission cable |
1 |
|
3 |
Opening/closing control line |
1 |
|
4 |
External trigger detection line |
1 |
|
5 |
Transparent ground dedicated line |
1 |
|
6 |
Fracture test line |
10 (4 m +6 m, yellow, green, red, black) |
|
7 |
Short-circuit cable (0.5 m black) |
2 |
|
8 |
Dedicated Ground line |
1 |
|
9 |
Power cord |
1 |
|
10 |
Linear travel speed sensor |
1 |
|
11 |
Universal Magnetic base |
1 |
|
12 |
Permanent magnet base |
1 |
|
13 |
Fixed installation accessories |
1 |
|
14 |
Thermal printing paper |
2 |
|
15 |
Instruction manual |
1 |
|
16 |
Inspection report |
1 |
|
17 |
Certification |
1 |
